Load Rite - 2019 Galvanized SA® & TAB Bunk Trailers

Load Rite - 2018 Galvanized Multi-Axle SA & TAB Bunk Trailers

Load Rite's SA® Bunk models offer a hybrid support system, combining the articulation of a roller model with the hull contact area of a bunk, resulting in greater hull surface contact. Easy to load and launch, SA® Bunk Models are a great alternative to traditional bunk systems.

TAB-Bunk models combine Load Rite's galvanized steel bunk tube from their AB Aluminum models with a heavy duty galvanized steel frame. The result is simply the heaviest duty bunk trailer available. The bunk system provides the most adjustability and the best support of any bunk design of its size on the market today. Thoughtfully designed with space between the front and rear bunks to accommodate sling loading. Adjustable vertically, laterally and horizontally, the bunks also pivot to conform to hull deadrise.

Add Aluminum wheels for a stylish model that can handle the largest of trailerable boats.

Load Rite 24T6100TSA2 Load Rite 24T6100TSA2

AB - Steel Tube Mounted

SA® - Self-Adjusting

Self Adjusting (SA®) Bunk Trailers


Galvanized ModelCapacityBow Eye To Transom MaximumBow Eye To Transom MinimumBunk TypeBrakesTire SizeOverall WidthBetween FendersOverall Length
22T3800TSA13,80020' 3"17' 1"SA1, 2ST175/R13C98"77"24' 6"
22T4700TSA14,70020' 3"17' 1"SA1, 2ST205/R14C98"77"24' 6"
22T5000TSA15,00020' 3"17' 1"SA1, 2ST205/R14C98"77"24' 6"
22T5400TSA15,40020' 3"17' 1"SA1, 2ST215/R14C98"77"24' 6"
24T5000TSA15,00023' 2"18' 2"SA1, 2ST205/R14C98"77"26' 10"
24T5400TSA15,40023' 2"18' 2"SA1, 2ST215/R14C98"77"26' 10"
24T6100TSA16,10023'19' 6"SA1, 2ST215/R14C98"77"26' 10"
25T6000TSA16,00024'20' 1"SA1, 2ST215/R14C98"77"27' 7"
25T6400TSA16,40024'20' 7"SA1, 2ST205/R15D98"77"28'

Load Rite 24T5000TSA Load Rite 24T5000TSA

TAB Bunk Trailers


Galvanized ModelCapacityBow Eye
To Transom Maximum
Bow Eye
To Transom Minimum
Bunk TypeBrakesTire SizeOverall WidthBetween FendersOverall Length
26T8000TAB28,00024' 8"22' 3"AB2ST225/R15D98"77"28'
26T9700TAB29,70025'23' 5"AB2ST235/R16D98"77"29'
27T7400TAB17,40025'22' 3"AB1, 2ST225/R15D98"77"28'
28T8200TAB28,20027'24' 2"AB2ST225/R15D98"77"30'
28R9000TAB39,00026'24' 5"AB3ST215/R14C98"80"30'
29T9700TAB29,70027'24' 2"AB2ST235/R16D98"77"32' 4"
30R11500TAB311,50027' 4"24'AB3ST225/R75D98"80"31' 10"
30R12500TAB312,50027' 4"24'AB3ST235/R16D98"80"31' 10"
34R15000TAB315,00030' 9"26'AB3ST235/R16D98"80"36'
34R18000TAB318,00030' 9"26'AB3ST235/R16D98"80"36'
39R17400TAB317,40036'28'AB3ST235/R16D98"80"40' 6"
Load Rite 25T6400TSA1 Load Rite LR-25T6400TSA1

Features

Standard Features

Popular Options

Galvanized Steel FrameSecond Axle Brakes
Radial TiresElectric Over Hydraulic Brakes
Bead-Balanced wheel AssembliesAluminum Wheels
Torsion AxlesStainless Disc Brake Options
Disc BrakesVAULT or Vortex Hubs*
LED LightingStainless brakelines
Galvanized Steel Bunk Support TubesQuick-Slide Bunk Covers
Carpeted Wood BunksDrop Style Tongue Jack
One-Piece Aluminum Diamond-Plate Fenders (>90" Wide)Heat Shrunk Wire Splices
Tongue Jack
Drop Style Tonge Jack (Tri-Axle Models)
2 Plus 3 Years Coupler to Taillight Warranty
