Venture - Bunk Trailers
2018 Venture Bunk Trailers
| Model | Capacity | *Boat Length | Overall Length | Bow Eye to Transom Minimum | Bow Eye to Transom Maximum | GVWR | Tongue Jack | # of Axles | Brakes | Tire Size | Overall Width | Between Fenders |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| VB-1000 | 1000 | 12'-14' | 15' | 8'6" | 13' | 1270 | Optional | 1 | No | 4.80 x 12 LRC 4H | 60" | 42" |
| VB-1300 | 1300 | 14'-15' | 17'6" | 8'6" | 15'6" | 1570 | Optional | 1 | No | 4.80 x 12 LRC 4H | 60" | 42" |
| VB-1500 | 1500 | 14'-15' | 17'6" | 10'6" | 14'6" | 1875 | Optional | 1 | No | 5.30 x 12 LRC 5H | 78" | 60" |
| VB-1800 | 1800 | 15'-16' | 19'6" | 10'6" | 16'6" | 2350 | Optional | 1 | No | 5.30 x 12 LRD 5H | 78" | 60" |
| VB-2000 | 2000 | 16'-17' | 19' | 14' | 16'6" | 2550 | Optional | 1 | No | ST175/80D 13 LRC 5H | 84" | 67" |
| VB-2200 | 2200 | 17'-18' | 20' | 14' | 17'6" | 2750 | Optional | 1 | No | ST185/80D 13 LRD 5H | 84" | 67" |
| VB-2400 | 2400 | 17'-18.5' | 21' | 14' | 18'6" | 3190 | Optional | 1 | No | ST205/75D 14 LRC 5H | 88" | 67" |
| VB-2600 | 2600 | 18'-19' | 22'6" | 15' | 18' | 3380 | Optional | 1 | Optional | ST205/75D 14 LRC 5H | 100" | 81" |
| VB-2800S | 2800 | 18'-20' | 22'6" | 15' | 18' | 3580 | Optional | 1 | Optional | ST205/75D 15 LRC 5H | 100" | 81" |
| VB-2800 | 2800 | 20'-21' | 23'6" | 16' | 20' | 3625 | Optional | 1 | Optional | ST205/75D 15 LRC 5H | 100" | 81" |
| VB-3000S | 3000 | 18'-20' | 22'6" | 15' | 18' | 3780 | Single Wheel | 1 | Disc | ST215/75D 14 LRC 5H | 100" | 81" |
| VB-3100 | 3100 | 20'-21' | 23'6" | 16' | 20' | 3975 | Single Wheel | 1 | Disc | ST215/75D 14 LRC 5H | 100" | 81" |
| VB-3300 | 3300 | 20'-21' | 23'6" | 16' | 20' | 4175 | Single Wheel | 1 | Disc | ST225/75D 15 LRD 6H | 100" | 81" |
| VBT-3600S | 3600 | 18'-20' | 22'6" | 15' | 19' | 4600 | Single Wheel | 2 | Disc-1 | ST205/75D 14 LRC 5H | 100" | 81" |
| VBT-3700 | 3700 | 21'-23' | 24'6" | 17' | 21' | 4750 | Single Wheel | 2 | Disc-1 | ST205/75D 14 LRC 5H | 100" | 81" |
| VBT-4200 | 4200 | 21'-23' | 24'6" | 17' | 21' | 5250 | Single Wheel | 2 | Disc-1 | ST205/75D 14 LRC 5H | 100" | 81" |
| VBT-4700 | 4700 | 21'-23' | 24'6" | 17' | 21' | 5750 | Single Wheel | 2 | Disc-1 | ST205/75D 14 LRC 5H | 100" | 81" |
| VBT-5200 | 5200 | 21'-23' | 24'6" | 17' | 21' | 6250 | Single Wheel | 2 | Disc-1 | ST205/75D 15 LRC 5H | 100" | 81" |
| VBT-5600 | 5600 | 21'-23' | 24'6" | 17' | 21' | 6650 | Single Wheel | 2 | Disc-1 | ST205/75D 15 LRC 5H | 100" | 81" |
| VBT-5900 | 5900 | 24'-25' | 27'6" | 19' | 24' | 7300 | 2000lb. Foot | 2 | Disc-1 | ST225/75D 15 LRD 5H | 100" | 81" |
| VBT-6400 | 6400 | 25'-26' | 27'6" | 19' | 24' | 7825 | 2000lb. Foot | 2 | Disc-1 | ST225/75D 15 LRD 6H | 100" | 81" |
| VBT-7400 | 7400 | 25'-27' | 27'6" | 19' | 24' | 8825 | 2000lb. Foot | 2 | Disc-1 | ST225/75D 15 LRD 6H | 100" | 81" |
| VBT-7900 | 7900 | 25'-27' | 28' | 20' | 25' | 9350 | 2000lb. Foot | 2 | Disc-1 | ST225/75D 15 LRD 6H | 100" | 81" |
| VBT-8600 | 8600 | 27'-28' | 31'6" | 22' | 26'6" | 10250 | 2000lb. Foot | 3 | Disc-2 | ST205/75D 14 LRC 5H | 100" | 81" |
| VBT-9200 | 9200 | 28'-30' | 33' | 22' | 28' | 10900 | 2000lb. Foot | 3 | Disc-2 | ST225/75D 15 LRD 6H | 100" | 81" |
| VBT-10800 | 10800 | 29'-31' | 33' | 22' | 28' | 12500 | 2000lb. Foot | 3 | Disc-2 | ST225/75D 15 LRD 6H | 100" | 81" |
